M/B Form Factor
Micro-ATX (M-ATX) / Mini-ITX
Drive bays
3.5" HDD Bays: 3 internal slots2.5" SSD Bays: 2 internal slots5.25" ODD Bays: None (No support for legacy external optical drives)
Max CPU cooler height
Up to 155 mm
Max VGA card length
Up to 270 mm (Limits build options strictly to single-fan or shorter dual-fan graphics cards)
Cooling System
: Includes 2 x 120mm Fixed RGB fans pre-mounted at the front intake position out of the box to deliver immediate ventilation. (Supports up to 7 fans total for tailored directional airflow):Front: 2 x 120 mm fans (Pre-installed)Top: 2 x 120 mm fans (Optional)Bottom (PSU Shroud): 2 x 120 mm fans (Optional)Rear: 1 x 120 mm fan (Optional). Liquid Cooling Radiator Support:Top: 120 / 240 mm liquid AIO water-cooling loop kits (Subject to strict RAM profile clearance due to the narrow 190mm body width)Rear: 120 mm radiator loops
Material of Chassis
Black Coated Steel Plate Framework + ABS Plastic + Tempered Glass Side Window
I/O panel
1 x USB 3.0, 1 x USB 2.0, 1 x HD Audio Jack, 1 x Microphone Jack
Product Size
Micro-ATX (M-ATX) / Mini-ITX
Packing Size
(LxWxH): 364 × 237 × 418 mm
NW
(N.W.): ~2.85 kg (Extremely lightweight frame built with budget-oriented 0.4mm–0.45mm steel structural layers)
GW
(G.W.): ~3.80 kg (Total estimated weight packaged inside its retail box; marketplace couriers calculate a dimensional volumetric profile between 13 kg to 14 kg)
