M/B Form Factor
Micro-ATX (M-ATX) / Mini-ITX
Drive bays
1 x 3.5" HDD Bay1 x 2.5" SSD Bay5.25" ODD Bays: None (No support for legacy external optical CD/DVD drives)
Max CPU cooler height
Up to 160 mm
Max VGA card length
Up to 400 mm (Extremely spacious, easily clears massive flagship graphics cards)
Cooling System
(Supports up to 9 fans total for excellent directional airflow):Top: 3 x 120 mm fans.Bottom (PSU Shroud): 3 x 120 mm fans.Front / Side Tray: 2 x 120 mm fans.Rear: 1 x 120 mm fan. Liquid Cooling Radiator Support:Top: 120 / 240 / 360 mm liquid AIO water-cooling systems (highly rare and spacious for an mATX case class).Rear: 120 mm radiator loops
Material of Chassis
Heavy-Duty 0.7mm SPCC Steel + Premium Wood Style Trim + Tempered Glass Side Panel
I/O panel
1 x USB Type-C, 1 x USB 3.0, 1 x USB 2.0 (or 1.0), HD Audio
Product Size
420 × 215 × 395 mm
Packing Size
420 x 215 x 395 mm
NW
~5.10 kg (Chassis built with a thick, heavy-duty 0.7mm SPCC steel structure framework)
GW
~6.20 kg (Total estimated weight packaged inside its retail box with high-density protective foam cushions)
